MSK-SFM-9 Double Planetary Vacuum Mixer
Product description:
MSK-SFM-9 double planetary four-blade vacuum mixer is a high-efficiency mixing equipment integrating vacuum low-speed mixing and high-speed dispersion. It can be applied to various solvent and powder mixing processes, such as lithium ion batteries, tapes, solar energy, Chemical ingredients and other raw materials. The integrated design of the device is small and exquisite, with good mixing uniformity and convenient and easy to use.
Factory Price, Hige Quality
Description
Features:
Biaxial planetary agitation, twist-frame agitation paddles with high-speed dispersing discs and scraping walls, no dead corners for agitation
Low-speed mixing achieves macro mixing through revolution and rotation, and high-speed dispersing disk achieves micro mixing through shearing force;
The vacuum environment effectively eliminates the air bubbles generated during the stirring process, and the vacuum maintenance effect is good;
The effective volume of the mixing tank is 5L, which is made of high-quality SUS304 stainless steel, which is resistant to acid and alkali corrosion;
Multi-speed operation can be performed, and the stirring speed and time of each step can be set;
Slurry tank lift design with spotlights for easy operation and safety during vacuum mixing;
Various electrical safety designs such as PLC control, HMI operation, motor overload protection;
Jacketed mixing tank design can pass cooling water, which is suitable for a variety of process requirements;
Technical Parameters
| power supply | Single-phase voltage 220VAC ± 10% (110VAC can be customized), frequency 50Hz / 60Hz, power 4KW |
| Use environment | Recommended ambient temperature 25 ± 3 ℃, humidity 30 ~ 90RH, no vibration and electromagnetic interference |
| impeller | Two twist-frame agitating paddles, a dispersion plate, and a scraper (made of Teflon) |
| Revolution speed | Max.70rpm |
| Rotation speed | Max.112rpm |
| Dispersion speed | Max.6100rpm |
| Feed interface | DN50 |
| Vacuum system | Standard vacuum pump 2XZ-2, vacuum degree -0.098Mpa |
| Stiring time | 0 ~ 999min can be set |
| Slurry temperature | Bucket wall temperature measurement, HMI display, can be cooled by cooling water |
| Sealing material | Maximum effective volume 5L, design volume 8L |
| Installation size | L1080mm*W980mm*H1970mm; L 42.5 inch *W 38.6 inch *H 77.6 inch |
| Weight | About 700Kg |
